Y-S06 - Stainless Steel Cable & Rod Railing Post
Model Y-S06 is a stainless steel railing post designed for cable railing and stainless steel rod railing systems. It provides an open and minimalist railing configuration and can be customized for different architectural layouts, railing heights and project requirements.
Stainless Steel Cable & Rod Railing Post – Model Y-S06
Model Y-S06 is a stainless steel railing post designed for cable railing and stainless steel rod railing systems. It provides an open and minimalist railing configuration and can be customized for different architectural layouts, railing heights and project requirements.
Product Overview
The Y-S06 system can be configured with stainless steel rods or stainless steel cables according to the desired railing design. Stainless steel 304 or 316L is available, with matte/brushed or polished finishes.
The post dimensions, height, mounting configuration and infill arrangement can be customized according to the project. This makes Y-S06 suitable for both standard applications and project-specific railing systems.
Key Features
- Designed for stainless steel cable or rod railing systems
- Stainless steel 304 / 316L
- Stainless steel rods or fine stainless steel cables available
- Matte/brushed or polished finishes
- Custom post height and dimensions
- Floor, side/fascia and embedded mounting options
- Project-specific configuration and engineering support
Technical Specifications
| Model | Y-S06 |
| Product Type | Stainless Steel Cable / Rod Railing Post |
| Material | Stainless Steel 304 / 316L |
| Surface Finish | Matte / Brushed / Polished |
| Infill Options | Stainless Steel Rod / Stainless Steel Cable |
| Mounting | Floor / Side / Embedded |
| Dimensions | Customizable |
Custom Design & Structural Support
Y-S06 can be customized according to the railing layout, required height, infill type, mounting condition and project design. Newkin Material can develop project-specific configurations rather than limiting the railing system to fixed standard dimensions.
For projects with specific structural requirements, our team can assist with product configuration and load calculations based on the applicable project parameters. This can help determine suitable post dimensions, spacing and mounting configurations for the intended application.
Applications
- Stainless steel cable balcony railing
- Deck and terrace railing
- Staircase cable railing
- Garden and courtyard railing
- Interior cable railing
- Commercial and residential railing systems
Design Your Custom Cable Railing
Send us your railing layout, dimensions or project requirements for customized product design and technical support.
Contact Us for Custom Design
