F01 - Stainless Steel Square Tube Railing Post
Model F01 is a stainless steel square tube railing post designed for contemporary glass railing systems. Its straight-line profile provides a clean architectural appearance and can be customized for different railing heights, glass specifications and structural requirements.
Stainless Steel Square Tube Railing Post – Model F01
Model F01 is a stainless steel square tube railing post designed for contemporary glass railing systems. Its straight-line profile provides a clean architectural appearance and can be customized for different railing heights, glass specifications and structural requirements.
Product Overview
Model F01 is manufactured from stainless steel 304 or 316L and is available with matte/brushed or polished finishes. It is designed for 12–18 mm glass, with customized configurations available for project-specific requirements.
The square tube profile is suitable for modern architectural projects where a geometric post design is preferred. The post can be customized in terms of height, thickness, dimensions and mounting configuration.
Key Features
- Square tube stainless steel railing post
- 304 / 316L stainless steel
- 12–18 mm glass compatibility
- Matte/brushed or polished finish
- Custom tube dimensions, thickness and height
- Floor, side/fascia and embedded mounting
- Suitable for custom architectural railing systems
Technical Specifications
| Model | F01 |
| Product Type | Stainless Steel Square Tube Railing Post |
| Material | Stainless Steel 304 / 316L |
| Finish | Matte / Brushed / Polished |
| Glass Thickness | 12–18 mm, customizable |
| Mounting | Floor / Side / Embedded |
| Dimensions | Customizable |
Custom Design & Load Calculation
F01 can be adapted to project-specific architectural and structural requirements. Customers can provide drawings, railing dimensions, glass specifications and installation conditions for technical evaluation.
Newkin Material can assist with customized product design and project-specific load calculations based on the required design parameters. Tube dimensions, wall thickness, post height, mounting configuration and other connection details can be developed according to the application.
Applications
- Modern glass balcony railings
- Staircase guardrails
- Terrace and deck railings
- Courtyard railings
- Interior architectural railings
- Custom commercial railing systems
Need a Custom Square Tube Railing Post?
Send your drawings or project specifications for customized design, technical evaluation and quotation.
Contact Us for Custom Design
